| Part Number | ALC70C102FP600 | Manufacturer | KEMET |
|---|---|---|---|
| Category | Aluminum Electrolytic Capacitors | Capacitance | 1000 µF |
| Mounting Type | Through Hole | Tolerance | ±20% |
| Package / Case | Radial, Can - Snap-In - 4 Lead | Voltage - Rated | 600 V |
| ESR (Equivalent Series Resistance) | 132.3mOhm @ 100Hz | Lifetime @ Temp. | 18000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C | Ripple Current @ Low Frequency | 5.75 A @ 100 Hz |
| Size / Dimension | 1.772" Dia (45.00mm) | Ripple Current @ High Frequency | 11.48 A @ 10 kHz |
| Surface Mount Land Size | - | Height - Seated (Max) | 4.213" (107.00mm) |
